RC10B6 FT Bulkhead, 25 deg, 30 deg, steel
The chassis plate on most 1:10 Team Associated race vehicles (RC10B6.3, RC10T6.2, RC10SC6.2) is manufactured with a 27.5 degrees kickup angle at the nose.
These bulkheads allow for adjustment between 25 degrees and 30 degrees of kickup depending on the direction it is installed.
Install the "-2.5Deg" or "25Deg" side of the bulkhead towards the front of the car for 25 degrees of kickup.
Install the "+2.5Deg" or "30Deg" side of the bulkhead towards the front of the car for 30 degrees of kickup.
